Drive Axle for Forklift

Drive Axle for Forklift - A lift truck drive axle is a piece of machinery that is elastically affixed to a vehicle framework with a lift mast. The lift mast is attached to the drive axle and can be inclined round the drive axle's axial centerline. This is accomplished by at least one tilting cylinder. Frontward bearing components together with back bearing elements of a torque bearing system are responsible for fastening the drive axle to the vehicle framework. The drive axle could be pivoted round a swiveling axis oriented horizontally and transversely in the vicinity of the rear bearing components. The lift mast is also capable of being inclined relative to the drive axle. The tilting cylinder is attached to the vehicle framework and the lift mast in an articulated fashion. This allows the tilting cylinder to be oriented almost parallel to a plane extending from the axial centerline and to the swiveling axis.

Unit H45, H35 and H40 forklifts, that are made by Linde AG in Aschaffenburg, Germany, have a connected lift mast tilt on the vehicle framework itself. The drive axle is elastically affixed to the frame of the forklift using numerous different bearings. The drive axle consists of tubular axle body along with extension arms attached to it and extend rearwards. This particular kind of drive axle is elastically attached to the vehicle framework utilizing rear bearing parts on the extension arms together with forward bearing devices situated on the axle body. There are two back and two front bearing devices. Each one is separated in the transverse direction of the vehicle from the other bearing machine in its respective pair.

The drive and braking torques of the drive axle on tis particular model of lift truck are sustained using the extension arms through the back bearing components on the framework. The forces produced by the lift mast and the load being carried are transmitted into the floor or road by the vehicle frame through the front bearing components of the drive axle. It is important to make certain the components of the drive axle are put together in a firm enough way so as to maintain immovability of the lift truck truck. The bearing elements can reduce small bumps or road surface irregularities through travel to a limited extent and offer a bit smoother operation.
